T43B
-
WhatsApp：8618694087250
T43B
All-in-one covert hideaway warning/position module, 18.5×18.5×21.57 mm, black bezel, Fresnel optical design, available in single color. Operating voltage: 10–33 V DC, maximum current: 0.62 A @12V / 0.35 A @24V. Flash patterns: 14. LED quantity: 3W × 3 pcs. Lens material: PC. Mounting: Flush Mount / Tube Flush Mount. Protection: IP67. Operating temperature: -30℃ to +70℃. Certified: ECE R10, ECE R65 Class 1 (4 units for a group), SAE J595 Class 2. Warranty: 3 years. Colors: blue.
contact us
Description
All-in-one covert hideaway warning/position module, 18.5×18.5×21.57 mm, with sleek black bezel.
Fresnel optical system for precise and sharp light output.
Single color configuration available (blue).
Wide voltage range: 10–33 V DC, current 0.62 A @12V / 0.35 A @24V.
Flash patterns: 14.
high-intensity LEDs: 3W × 3 pcs.
Durable PC lens with IP67 protection.
Flexible mounting options: Flush Mount / Tube Flush Mount.
Certified: ECE R10, ECE R65 Class 1 (4 units for a group), SAE J595 Class 2.
Warranty: 3 years.
Fresnel optical system for precise and sharp light output.
Single color configuration available (blue).
Wide voltage range: 10–33 V DC, current 0.62 A @12V / 0.35 A @24V.
Flash patterns: 14.
high-intensity LEDs: 3W × 3 pcs.
Durable PC lens with IP67 protection.
Flexible mounting options: Flush Mount / Tube Flush Mount.
Certified: ECE R10, ECE R65 Class 1 (4 units for a group), SAE J595 Class 2.
Warranty: 3 years.
Specifications
| Product Name | T43B |
|---|---|
| Categories | Covert Hideaway, Modules |
| Dimensions (L×W×H)mm | 18.5*18.5*21.57 |
| Function | Warning/Position Light |
| Bezel Colour | Black |
| Optical | Fresnel |
| Color Type | Single |
| Operating Voltage | 10-33V DC |
| Maximum Current | 0.62A@12VDC / 0.35A@24VDC |
| Color Modes | Blue |
| Flash Patterns | 14 |
| LED Quantity | 3W × 3PCS |
| Lens Material | PC |
| Mounting Options | Flush Mount / Tube Flush Mount |
| IP Rating | 67 |
| Operating Temperature | -30℃—+70℃ |
| Certifications | ECE R10, ECE R65 Class 1 (4 units for a group), SAE J595 Class 2 |
| Warranty | 3-year |
